The fan is made of metal support, built-in centrifugal fan and ABS plastic cover. It is widely applied to electrical products and cabinets.
Centrifugal top ventilator can exhaust heat load with high efficiency.
It can work under electromagnetic environment, meanwhile, it won't interfere the system or equipment where it installed.
Running temperature/humidity: (unconcretionary) Temperature: -30℃ ~ +80℃ Humidity: 0% ~ 95%
RAL 7035 grey is the standard color, can be changed to RAL 7032.
Protection class: E N 60 5 29 I P 33 / IP54 (not suitable for outdoor equipment).
References are based on the frame dimension, which helps you to quickly select the best choice for your installation.
Example:
When your installation space is enough for dimention 120*120*38mm, please choose FJ1203
When you choose AC 220V, frame size 120x120x38mm, sleeve bearing, plug-in connection, please choose model FJ12032AST
We can customize your unconventional products.
Characteristics:
1.The fan is made of metal support, built-in centrifugal fan and ABS plastic cover. It is widely applied to electrical products and cabinets.
2.Centrifugal top ventilator can exhaust heat load with high efficiency.
3.It can work under electromagnetic environment, meanwhile, it won't interfere the system or equipment where it installed.
4.Running temperature/humidity: (unconcretionary) Temperature: -30℃ ~ +80℃ Humidity: 0% ~ 95%
5.RAL 7035 grey is the standard color, can be changed to RAL 7032.
6.Protection class: E N 60 5 29 I P 33 / IP54 (not suitable for outdoor equipment).
Parameters
|
Type |
Fan Model |
Rated Voltage |
Speed |
Frequency |
current |
Power |
Max Air Flow |
Static Pressure |
Noise |
Curve |
external dimensions |
|
V |
V
|
Hz |
(A) |
(W)+10%-20% |
m3/h |
(Pa) |
(dB) |
(mm) |
|||
|
FJK190PB-230 |
C2E-190.45A |
230 AC |
150...250 |
50 |
0.26 |
58 |
484 |
265 |
57 |
① |
310x310x140 |
|
60 |
0.33 |
74 |
527 |
335 |
59 |
||||||
|
FJK220PB-230 |
C2E-220.44B |
230 AC |
150...250 |
50 |
0.46 |
98 |
730 |
300 |
60 |
② |
|
|
60 |
0.51 |
118 |
830 |
440 |
62 |
||||||
|
FJK225PB-230 |
C2E-225.63C |
230 AC |
150...250 |
50 |
0.60 |
131 |
1020 |
430 |
62 |
③ |
|
|
60 |
0.74 |
170 |
1140 |
585 |
64 |
|
|
|
|
Wide range fan High efficient air flow , high protection class , fast installation , easy connection of power supply |
Fast tool-less installation both insert installation and screw installation type are available |
|
|
|
|
High efficient exhaust design, 50% increase average Ventilation shutter maximal optimized the air circulation |
Easy maintain Fast filter pad replacement Fast , easy and safe filter pad replacement, even during operation
|
|
|
|
|
Minimized air pressure wastage Improvement of fan installation distance to filter and perfect reliable design of air room is verified by study and test to be better aerodynamics and less air pressure loss. |
Thermoduric seal loop Polyurethane gasket assures long-term seal |
|
|
|
|
Environment Recycling plastic and filter pad Fan motor according to RoHS |
|
