Frame: Aluminium alloy die-casting, surfaces is finished by black anti-corrosion treatment.
Impeller: Black plastic PBT UL94V-0 (5 Blades/7 Blades)
Operation Temperature/Humidity Range: (under unconcretionary state) -40℃ ~ +65℃ (temperature), 0% ~ 95% (himidity)
Protection: Impedance Protected
Withstand Voltage: AC 1,800V , 1 min at 0.5mA, 50/60 Hz
Insulation System: Design according to IEC61858 Grade B,
Protection Grade: IP34
References are based on the frame dimension, which helps you to quickly select the best choice for your installation.
Example:
When your installation space is enough for dimention 120*120*38mm, please choose FJ1203
When you choose AC 220V, frame size 120x120x38mm, sleeve bearing, plug-in connection, please choose model FJ12032AST
We can customize your unconventional products.
Frame
Aluminium alloy die-casting, surfaces is finished by black anti-corrosion treatment.
Impeller
Black plastic PBT UL94V-0 (5 Blades/7 Blades)
Operation Temperature/Humidity Range: (under unconcretionary state)
-40℃ ~ +65℃ (temperature), 0% ~ 95% (himidity)
Protection
Impedance Protected
Withstand Voltage
AC 1,800V , 1 min at 0.5mA, 50/60 Hz
Insulation System
Design according to IEC61858 Grade B,
Protection Grade
IP34
|
Type |
Motor |
Rated Voltage |
Frequency |
current |
Power |
Speed |
Max Air Flow |
Static Pressure |
Noise |
Curve |
Capacitor Motor |
|
|
V |
Hz |
(A) |
(W)+10%-20% |
(min-1) |
CFM |
m3/h |
(Pa) |
(dB) |
(μF) |
|||
|
FJ15051ABH |
M2S7402-BB |
115 |
50 |
0.34 |
25 |
2500 |
237 |
402 |
160 |
55 |
② |
7 Blades |
|
60 |
0.32 |
23 |
2700 |
246 |
417 |
180 |
57 |
|||||
|
FJ15052ABH |
M2E7402-BB |
230 |
50 |
0.48 |
41 |
2600 |
237 |
402 |
160 |
55 |
||
|
60 |
0.46 |
38 |
2700 |
246 |
417 |
180 |
57 |
|||||
|
FJ15053ABH |
M2D7402-BB |
380 |
50 |
0.19 |
26 |
2500 |
237 |
402 |
160 |
55 |
||
|
60 |
0.17 |
24 |
2700 |
246 |
417 |
180 |
57 |
|||||
|
FJ15051AB |
M2S7401-BB |
115 |
50 |
0.34 |
25 |
2450 |
130 |
220 |
80 |
50 |
① |
5 Blades |
|
60 |
0.32 |
23 |
2650 |
142 |
240 |
100 |
52 |
|||||
|
FJ15052AB |
M2E7401-BB |
230 |
50 |
0.19 |
26 |
2450 |
130 |
220 |
80 |
50 |
||
|
60 |
0.17 |
24 |
2650 |
142 |
240 |
100 |
52 |
|||||
